Question 19

Give a method to obtain a quadrilateral whose area is half that of a given quadrilateral.

Check your answer with HomiSolve it yourself, then let Homi check your steps and spot mistakes.
Solution

FIO-19

Chapter: AREA OF POLYGONS
Class: 8 (Class 8)
Category: figure_it_out

Question

Give a method to obtain a quadrilateral whose area is half that of a given quadrilateral.

We can find a quadrilateral with half the area of a given one by connecting the middle points of its sides.

Step 1 — Setting up our quadrilateral

Let's start with any four-sided shape, called a quadrilateral. We will call its corners A, B, C, and D. Now, let's find the middle point of each side. The middle point of side AB is P. The middle point of side BC is Q. The middle point of side CD is R. The middle point of side DA is S. Next, we connect these middle points in order: P to Q, Q to R, R to S, and S back to P. This creates a new quadrilateral inside, called PQRS.

Diagram 1

Step 2 — Understanding the inner shape

Let's draw a line connecting corners A and C. This line is called a diagonal. Look at the triangle ABC. P is the midpoint of AB, and Q is the midpoint of BC. There's a special rule called the Midpoint Theorem. It says that the line connecting the midpoints of two sides of a triangle is parallel to the third side. It also says this connecting line is half the length of the third side. So, PQ is parallel to AC. The length of PQ is half the length of AC. PQ∥ACPQ \parallel AC PQ=12ACPQ = \frac{1}{2} AC Now look at triangle ADC. S is the midpoint of DA, and R is the midpoint of CD. Using the Midpoint Theorem again, SR is parallel to AC. The length of SR is half the length of AC. SR∥ACSR \parallel AC SR=12ACSR = \frac{1}{2} AC Since both PQ and SR are parallel to AC, they must be parallel to each other. Also, since both PQ and SR are half the length of AC, they must have the same length. So, PQ and SR are parallel and equal in length. A quadrilateral with opposite sides that are parallel and equal is a parallelogram. Therefore, the quadrilateral PQRS is a parallelogram.

Step 3 — Comparing triangle areas

Let's focus on triangle ABC again. P and Q are midpoints. This means triangle PBQ is similar to triangle ABC. They have the same angles, and their sides are in proportion. The ratio of their sides is 1:2. For example, PB is half of AB, and BQ is half of BC. Similar triangles have a special area relationship. The ratio of their areas is the square of their side ratio. So, the area of triangle PBQ is (1/2) squared, or 1/4, of the area of triangle ABC. Area(PBQ)=(12)2×Area(ABC)\text{Area(PBQ)} = \left(\frac{1}{2}\right)^2 \times \text{Area(ABC)} =14×Area(ABC)= \frac{1}{4} \times \text{Area(ABC)} We can do the same for the other three corner triangles: For triangle QCR, its area is 1/4 of the area of triangle BCD. Area(QCR)=14×Area(BCD)\text{Area(QCR)} = \frac{1}{4} \times \text{Area(BCD)} For triangle SDR, its area is 1/4 of the area of triangle CDA. Area(SDR)=14×Area(CDA)\text{Area(SDR)} = \frac{1}{4} \times \text{Area(CDA)} For triangle SAP, its area is 1/4 of the area of triangle DAB. Area(SAP)=14×Area(DAB)\text{Area(SAP)} = \frac{1}{4} \times \text{Area(DAB)}

Step 4 — Finding the area of PQRS

The area of PQRS is the area of ABCD. We subtract the areas of the four corner triangles. Area(PQRS)=Area(ABCD)−(Area(PBQ)+Area(QCR)+Area(SDR)+Area(SAP))\text{Area(PQRS)} = \text{Area(ABCD)} - (\text{Area(PBQ)} + \text{Area(QCR)} + \text{Area(SDR)} + \text{Area(SAP)}) Now, let's substitute the area relationships we found in Step 3: Area(PQRS)=Area(ABCD)−(14Area(ABC)+14Area(BCD)+14Area(CDA)+14Area(DAB))\text{Area(PQRS)} = \text{Area(ABCD)} - \left(\frac{1}{4} \text{Area(ABC)} + \frac{1}{4} \text{Area(BCD)} + \frac{1}{4} \text{Area(CDA)} + \frac{1}{4} \text{Area(DAB)}\right) We can take out the common factor of 1/4: Area(PQRS)=Area(ABCD)−14(Area(ABC)+Area(BCD)+Area(CDA)+Area(DAB))\text{Area(PQRS)} = \text{Area(ABCD)} - \frac{1}{4} (\text{Area(ABC)} + \text{Area(BCD)} + \text{Area(CDA)} + \text{Area(DAB)}) Let's look at the sum inside the bracket. The area of ABCD can be split in two ways. We use its diagonals to do this. Using diagonal AC, Area(ABCD) = Area(ABC) + Area(CDA). Using diagonal BD, Area(ABCD) = Area(BCD) + Area(DAB). The sum inside the bracket is (Area(ABC) + Area(CDA)). Then we add (Area(BCD) + Area(DAB)). This sum is Area(ABCD) plus Area(ABCD). So, the total sum is 2 times Area(ABCD). Area(ABC)+Area(BCD)+Area(CDA)+Area(DAB)=2×Area(ABCD)\text{Area(ABC)} + \text{Area(BCD)} + \text{Area(CDA)} + \text{Area(DAB)} = 2 \times \text{Area(ABCD)} Now, let's put this back into our equation for Area(PQRS): Area(PQRS)=Area(ABCD)−14(2×Area(ABCD))\text{Area(PQRS)} = \text{Area(ABCD)} - \frac{1}{4} (2 \times \text{Area(ABCD)}) =Area(ABCD)−24×Area(ABCD)= \text{Area(ABCD)} - \frac{2}{4} \times \text{Area(ABCD)} =Area(ABCD)−12×Area(ABCD)= \text{Area(ABCD)} - \frac{1}{2} \times \text{Area(ABCD)} =12×Area(ABCD)= \frac{1}{2} \times \text{Area(ABCD)}

Area(PQRS)=12×Area(ABCD)\boxed{\text{Area(PQRS)} = \frac{1}{2} \times \text{Area(ABCD)}}

Answer

(i) Start with the given quadrilateral, let's call it ABCD. (ii) Find the midpoint of each side: P on AB, Q on BC, R on CD, and S on DA. (iii) Connect these midpoints in order (P to Q, Q to R, R to S, S to P) to form a new quadrilateral PQRS. This quadrilateral PQRS will have an area exactly half of the area of ABCD.
