Question 22

"There is no chord of a circle that is longer than its diameter." How do you justify this statement?

Solution

Understand the Question

A square of side $s = 2\text{ units}$ contains a 4-petalled flower formed by intersecting circular arcs of radius $r = 2\text{ units}$ .
Each petal is bounded by $2$ quarter-circle arcs, giving a total of $4 \times 2 = 8$ quarter-circle arcs for the flower's perimeter.
The area of the flower is calculated by subtracting the area of the $4$ unshaded corner regions (circular segments) from the total area of the square.

(i) Find the perimeter of the flower.

Step 1 · Calculate the Perimeter of the Flower

The square has side length $s = 2\text{ units}$ . Each arc forming the petals is a quarter circle of radius $r = 2\text{ units}$ . Diagram 1

$\text{Side length of square } (s) = 2 \text{ units}$ $\text{Radius of each arc } (r) = s = 2 \text{ units}$

Length of one quarter-circle arc:

\begin{aligned} \text{Length of one quarter circle arc} &= \dfrac{1}{4} \times 2\pi r \\[0.6em] &= \dfrac{1}{2}\pi r \\[0.6em] &= \dfrac{1}{2}\pi (2) \\[0.6em] &= \pi \text{ units} \end{aligned}

Since the flower consists of $8$ identical arcs: $\text{Perimeter of flower} = 8 \times \pi = 8\pi \text{ units}$

Answer

(i) $8\pi \text{ units}$

(ii) Find the area of the flower.

Step 1 · Calculate Area of Square and Corner Segments

Area of the square:

\begin{aligned} \text{Area of square} &= s^2 \\ &= (2)^2 \\ &= 4 \text{ square units} \end{aligned}

Each unshaded corner region is a segment formed by a sector of angle $90^\circ$ and radius $r = 2\text{ units}$ minus a right isosceles triangle:

\begin{aligned} \text{Area of one sector} &= \dfrac{90^\circ}{360^\circ} \times \pi r^2 \\[0.6em] &= \dfrac{1}{4}\pi (2)^2 \\[0.6em] &= \pi \text{ square units} \end{aligned}

\begin{aligned} \text{Area of this triangle} &= \dfrac{1}{2} \times \text{base} \times \text{height} \\[0.6em] &= \dfrac{1}{2} \times 2 \times 2 \\[0.6em] &= 2 \text{ square units} \end{aligned}

Area of one unshaded corner segment:

\begin{aligned} \text{Area of one segment} &= \text{Area of sector} - \text{Area of triangle} \\ &= \pi - 2 \text{ square units} \end{aligned}

Total area of the $4$ unshaded regions:

\begin{aligned} \text{Total unshaded area} &= 4 \times (\pi - 2) \\ &= 4\pi - 8 \text{ square units} \end{aligned}

Area of the flower:

\begin{aligned} \text{Area of flower} &= \text{Area of square} - \text{Total unshaded area} \\ &= 4 - (4\pi - 8) \\ &= 4 - 4\pi + 8 \\ &= 12 - 4\pi \text{ square units} \end{aligned}

Answer

(ii) $(12 - 4\pi) \text{ square units}$

Common Mistakes

Arc Count Error: The flower has $4$ petals and each petal has $2$ arcs, making a total of $8$ quarter-circle arcs, not $4$ .
Sign Error in Subtraction: When subtracting total unshaded area, forgetting to distribute the negative sign: $4 - (4\pi - 8) = 12 - 4\pi$ , not $-4 - 4\pi$ .
Sector vs. Segment: Using the full sector area instead of the corner segment area (sector minus triangle) when subtracting unshaded regions.
