Question 13

Find the sidelength of a rhombus whose diagonals are of length 24 units and 70 units.

Check your answer with HomiSolve it yourself, then let Homi check your steps and spot mistakes.
Solution

We can find the side length of the rhombus by using its properties and the Pythagorean theorem.

Step 1 — Finding the lengths of half-diagonals

A rhombus is a special type of quadrilateral where all four sides are equal. Its diagonals cut each other exactly in half. They also meet at a perfect right angle (90 degrees).

Let the two diagonals of the rhombus be d1d_1 and d2d_2. We are given their lengths as 24 units and 70 units. So, d1=24d_1 = 24 units and d2=70d_2 = 70 units.

When the diagonals bisect each other, they form four smaller right-angled triangles inside the rhombus. The legs of these triangles are half the lengths of the diagonals.

Let the half-length of the first diagonal be h1h_1. h1=d12h_1 = \frac{d_1}{2} h1=242h_1 = \frac{24}{2}

h1=12 units\boxed{h_1 = 12 \text{ units}}

Let the half-length of the second diagonal be h2h_2. h2=d22h_2 = \frac{d_2}{2} h2=702h_2 = \frac{70}{2}

h2=35 units\boxed{h_2 = 35 \text{ units}}

Diagram 1

Step 2 — Using the Pythagorean Theorem

Each of the four triangles formed by the diagonals is a right-angled triangle. The sides of the rhombus are the hypotenuses of these triangles.

Let 'a' be the sidelength of the rhombus. In one of these right-angled triangles (for example, triangle AOD), the two shorter sides (legs) are h1h_1 and h2h_2. The longest side (hypotenuse) is 'a'.

The Pythagorean theorem states that in a right-angled triangle, the square of the hypotenuse is equal to the sum of the squares of the other two sides. So, a2=h12+h22a^2 = h_1^2 + h_2^2.

a2=122+352a^2 = 12^2 + 35^2

First, we calculate the squares of the half-diagonals. 122=12×12=14412^2 = 12 \times 12 = 144 352=35×35=122535^2 = 35 \times 35 = 1225

Now, we add these values together. a2=144+1225a^2 = 144 + 1225 a2=1369a^2 = 1369

To find 'a', we need to calculate the square root of 1369. a=1369a = \sqrt{1369}

a=37 units\boxed{a = 37 \text{ units}}

The sidelength of the rhombus is 37 units.

Answer

The sidelength of the rhombus is 37 units.
