Question 9
Context: Consider a square with its corners labeled A, B, C and D, and its vertical line of symmetry as shown in the figure.
Q. What if we reflect along the diagonal from A to C? Where do points A, B, C and D go? What if we reflect along the horizontal line of symmetry?
We find where each corner moves after reflection.
Step 1 — Reflect along diagonal AC
Look at the figure above. We reflect along the line from A to C. This line is a diagonal of the square. If a point is on the line. It stays in place. Point A is on the diagonal AC. So, A goes to A. Point C is on the diagonal AC. So, C goes to C. Point B is not on the diagonal AC. Imagine folding the square along AC. Point B will land on point D. So, B goes to D. Point D is not on the diagonal AC. Imagine folding the square along AC. Point D will land on point B. So, D goes to B.
Step 2 — Reflect along horizontal line of symmetry
Look at the figure above again. We reflect along the horizontal line of symmetry. This line goes through the middle of the square. It is halfway between AB and DC. Point A is at the top left. It moves to the bottom left. The bottom left point is D. So, A goes to D. Point B is at the top right. It moves to the bottom right. The bottom right point is C. So, B goes to C. Point C is at the bottom right. It moves to the top right. The top right point is B. So, C goes to B. Point D is at the bottom left. It moves to the top left. The top left point is A. So, D goes to A.
Answer
(i) For reflection along diagonal AC: A stays at A. B moves to D. C stays at C. D moves to B. (ii) For reflection along the horizontal line of symmetry: A moves to D. B moves to C. C moves to B. D moves to A.
