Question 20
Arrange these 7 pieces to form a rectangle. What will be the area of this rectangle in terms of the area of Shape C now? Give reasons for your answer.
Step 1 — Find the area of each piece
Let us call the area of Shape C as 1 unit. Look at the diagram. Shape E is exactly like Shape C. So, the area of Shape E is 1 unit.
Shape G is a square. We can see that two shapes like C can make a square like G. So, the area of Shape G is 2 units.
Shape D is a medium triangle. We can see that two shapes like C can make a triangle like D. So, the area of Shape D is 2 units.
Shape F is a parallelogram. We can see that two shapes like C can make a parallelogram like F. So, the area of Shape F is 2 units.
Shape A is a large triangle. We can see that four shapes like C can make a large triangle like A. So, the area of Shape A is 4 units.
Shape B is also a large triangle, just like Shape A. So, the area of Shape B is 4 units.
Step 2 — Calculate the total area of the square
The whole tangram puzzle forms a big square. The total area of this big square is the sum of the areas of all 7 pieces. Total Area = Area(A) + Area(B) + Area(C) + Area(D) + Area(E) + Area(F) + Area(G) So, the area of the big square is 16 times the area of Shape C.
Step 3 — Find the area of the rectangle
We are arranging these 7 pieces to form a rectangle. When we rearrange pieces, the total area does not change. The area of the rectangle will be the same as the total area of the original square. Area of the rectangle = Total Area of the square
Answer
The area of the rectangle will be . The reason is that rearranging the pieces does not change their total area. The original square's area is found to be 16 times the area of Shape C by comparing the sizes of all the pieces.
More questions in FIO
Find the missing terms:
a. Perimeter of a rectangle = 14 cm; breadth = 2 cm; length = ?.
b. Perimeter of a square = 20 cm; side of a length = ?.
c. Perimeter of a rectangle = 12 m; length = 3 m; breadth = ?.
A rectangle having sidelengths 5 cm and 3 cm is made using a piece of wire. If the wire is straightened and then bent to form a square, what will be the length of a side of the square?
Find the length of the third side of a triangle having a perimeter of 55 cm and having two sides of length 20 cm and 14 cm, respectively.
What would be the cost of fencing a rectangular park whose length is 150 m and breadth is 120 m, if the fence costs ₹40 per metre?
A piece of string is 36 cm long. What will be the length of each side, if it is used to form:
a. A square,
b. A triangle with all sides of equal length, and
c. A hexagon (a six sided closed figure) with sides of equal length?
A farmer has a rectangular field having length 230 m and breadth 160 m. He wants to fence it with 3 rounds of rope as shown. What is the total length of rope needed?
Find out the total distance Akshi has covered in 5 rounds.
Find out the total distance Toshi has covered in 7 rounds. Who ran a longer distance?
Think and mark the positions as directed—
a. Mark 'A' at the point where Akshi will be after she ran 250 m. b. Mark 'B' at the point where Akshi will be after she ran 500 m. c. Now, Akshi ran 1000 m. How many full rounds has she finished running around her track? Mark her position as 'C'. d. Mark 'X' at the point where Toshi will be after she ran 250 m. e. Mark 'Y' at the point where Toshi will be after she ran 500 m. f. Now, Toshi ran 1000 m. How many full rounds has she finished running around her track? Mark her position as 'Z'.
The area of a rectangular garden 25 m long is 300 sq m. What is the width of the garden?
What is the cost of tiling a rectangular plot of land 500 m long and 200 m wide at the rate of ₹8 per hundred sq m?
A rectangular coconut grove is 100 m long and 50 m wide. If each coconut tree requires 25 sq m, what is the maximum number of trees that can be planted in this grove?
By splitting the following figures into rectangles, find their areas (all measures are given in metres).
a. b.
Explore and figure out how many pieces have the same area.
How many times bigger is Shape D as compared to Shape C? What is the relationship between Shapes C, D and E?
Which shape has more area: Shape D or F? Give reasons for your answer.
Which shape has more area: Shape F or G? Give reasons for your answer.
What is the area of Shape A as compared to Shape G? Is it twice as big? Four times as big?
Hint: In the tangram pieces, by placing the shapes over each other, we can find out that Shapes A and B have the same area, Shapes C and E have the same area. You would have also figured out that Shape D can be exactly covered using Shapes C and E, which means Shape D has twice the area of Shape C or shape E, etc.
Can you now figure out the area of the big square formed with all seven pieces in terms of the area of Shape C?
Arrange these 7 pieces to form a rectangle. What will be the area of this rectangle in terms of the area of Shape C now? Give reasons for your answer.
Are the perimeters of the square and the rectangle formed from these 7 pieces different or the same? Give an explanation for your answer.
Find the areas of the figures below by dividing them into rectangles and triangles.
Give the dimensions of a rectangle whose area is the sum of the areas of these two rectangles having measurements: 5 m × 10 m and 2 m × 7 m.
The area of a rectangular garden that is 50 m long is 1000 sq m. Find the width of the garden.
The floor of a room is 5 m long and 4 m wide. A square carpet whose sides are 3 m in length is laid on the floor. Find the area that is not carpeted.
Four flower beds having sides 2 m long and 1 m wide are dug at the corners of a garden that is 15 m long and 12 m wide. How much area is now available for laying down a lawn?
Shape A has an area of 18 square units and Shape B has an area of 20 square units. Shape A has a longer perimeter than Shape B. Draw two such shapes satisfying the given conditions.
On a page in your book, draw a rectangular border that is 1 cm from the top and bottom and 1.5 cm from the left and right sides. What is the perimeter of the border?
Draw a rectangle of size 12 units × 8 units. Draw another rectangle inside it, without touching the outer rectangle that occupies exactly half the area.
A square piece of paper is folded in half. The square is then cut into two rectangles along the fold. Regardless of the size of the square, one of the following statements is always true. Which statement is true here?
a. The area of each rectangle is larger than the area of the square. b. The perimeter of the square is greater than the perimeters of both the rectangles added together. c. The perimeters of both the rectangles added together is always times the perimeter of the square. d. The area of the square is always three times as large as the areas of both rectangles added together.
